🚨 Struggling with Sludge Cleaning? We Solve It Safely & Efficiently. Are you dealing with:

• Toxic sludge in chemical tanks?
• Oil sludge in storage tanks?
• Heavy sediment in wastewater treatment systems?

❌ Manual cleaning is dangerous, slow, and costly
❌ Traditional dredging equipment lacks precision and safety

👉 YG Dredging Robot delivers fully remote, high-efficiency sludge removal — without human risk.

💰 Get Factory Direct Dredging Robot Price

✔ Custom solution in 24 hours
✔ Fast quotation & technical support
✔ Global delivery available

Click to get your price now

Dredging Robot Parameters

Parameter	YG500	YG600	YG700	YG800	YG900	YG1200
Robot Dimensions (mm)	1500*500*650	1500*600*650	1600*700*650	1600*850*700	1650*960*750	1900*1200*750
Dredging Width (mm)	500	600	700	800	900	Suitable for large culverts
Travel Speed (m/s)	3–15	3–15	3–15	3–15	3–15	0–17 m/min
Pump Diameter (inch)	3	3	4	4	4	4or6
Pump Flow (m³/h)	100	100	160	160	200	250
Pump Head (m)	0–30	0–30	0–25	0–25	0–25	0–30 (Horizontal: 100–150m)
Hydraulic Station Dimensions (mm)	2200*1200*1700	2200*1200*1700	2200*1200*1700	2200*1200*1700	2200*1200*1700	2120*1240*1200
Main Motor Power (kW)	18	18	22	22	22	45KW (50KW) or Diesel 76KW (123KW)
Hydraulic System Pressure (Mpa)	0–16	0–16	0–16	0–16	0–16	Not specified
Particle Size (mm)	15	15	40	40	50	0–40 (customizable)
Winch Speed (r/min)	0–10	0–10	0–10	0–10	0–10	0–10
Pipe Length (m)	30–50 Optional	30–50 Optional	30–50 Optional	30–50 Optional	30–50 Optional	30m/pack, 20kg pressure resistant, optional
Control System	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote
Lighting System	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2

Choose Your Sludge Cleaning Solution

🔥 Top Applications of Dredging Robot

1️⃣ Wastewater Treatment Plants

• Sedimentation tanks (primary & secondary)
• Sludge thickening tanks
• Industrial wastewater systems

💡 Why customers choose robots:

• Continuous sludge buildup
• Frequent cleaning required
• Strict environmental compliance

Widely used in wastewater plants worldwide, delivering fast ROI within months

2️⃣ Industrial & Chemical Sludge

• Chemical sedimentation tanks
• Electroplating sludge (heavy metals)
• Paper mill wastewater sludge

⚠️ Pain Points:

• Corrosive & toxic sludge
• Equipment damage risk
• Unsafe for workers

Explosion-proof system ensures safe operation in flammable and hazardous environments

3️⃣ Oil Tank Cleaning

• Oil storage tank bottom sludge
• Oil-water separation tanks
• Petrochemical sludge pools

⚠️ Risks:

• Poisoning & suffocation
• Flammable environment

100% remote-controlled operation — no need for workers to enter hazardous areas

4️⃣ Lakes & Environmental Dredging

• Municipal lakes & rivers
• Fish ponds & aquaculture farms
• Black & odorous water treatment

Quickly remove black sludge and restore clear water — fully compliant with environmental regulations

Upgrade to Unmanned Cleaning

Traditional Cleaning vs YG Dredging Robot

Method	Safety	Efficiency	Cost	Control
Manual Cleaning	❌ High Risk	❌ Slow	❌ High Labor	❌ Uncontrollable
Traditional Equipment	⚠️ Medium	⚠️ Limited	⚠️ Medium	❌ Poor Visibility
YG Dredging Robot	✅ Safe	✅ High Efficiency	✅ Lower Long-Term	✅ Fully Visualized

👉 Upgrade to intelligent dredging today

Key Advantages of Sludge Cleaning Robot

✅ Remote + Visual Operation

• HD underwater camera
• Real-time monitoring
• Accurate sludge removal

✅ Explosion-Proof & Anti-Corrosion

• Designed for chemical & oil environments
• Long service life

✅ Crawler System Stability

• Works on soft sludge & oil layers
• Anti-slip, anti-sinking

✅ Powerful Pump System

Handles high-viscosity sludge

Flow: 60–150 m³/h

Talk to an Expert Today

📊 Technical Highlights

• Pump Flow: 100–250 m³/h
• Head: up to 30m
• Particle Size: up to 50mm
• Wireless remote control
• Electric / Diesel optional

👉 Multiple models available (YG500–YG1200)

Real Customer Case | South Africa

✔ Completed lake sludge removal within 3 days, significantly improving water quality
✔ Successfully handled industrial oil sludge without stopping production
✔ Achieved fully unmanned operation, reducing labor costs and safety risks

💬 Customer Feedback:
“One machine solved both challenges efficiently while keeping our costs lower than expected.”

Explore Proven Solutions

Why Choose YG Machinery?

• 18+ years manufacturing experience
• Exported to 30+ countries
• Customizable solutions
• Full after-sales & remote support

📞 Get Your Dredging Robot Solution Now

👉 Tell us your project & get expert recommendation

WhatsApp / WeChat / Phone: +86 13837115193

✔ Fast response within 24 hours
✔ Free technical consultation
✔ Best factory price guaranteed

🔥 LIMITED OFFER – Contact Now

👉 Reduce labor cost, improve safety, increase efficiency

Send your inquiry now and get exclusive pricing!
