A hot melt road marking machine applies a durable and reflective coating of road marking paint. The machine works by heating the thermoplastic paint, often referred to as hot melt paint, and applying it to the surface using a spray or extrusion method. The thermoplastic paint hardens as it cools, creating strong and long-lasting markings that can withstand the wear and tear of daily traffic and harsh weather conditions.
Whether it’s highways, parking lots, or city streets, clear and durable road markings are essential for ensuring the safety and convenience of all road users. The hot melt road marking machine is a cutting-edge solution that meets the high standards of road marking, providing long-lasting and visible markings that withstand traffic and weather conditions.
Hot Melt Road Marking Machine Key Parameters
| Model | YG-CK360S | YG-CK380S |
| Thermoplastic Tank | 100kg, double stainless steel heating insulation barrels, plug-in manual mixer devices, removable devices | 100kg, double stainless steel heating insulation barrels, plug-in manual mixer devices, removable devices |
| Glass Bead Container | 10kg/box | 10kg/box |
| Adjustable glass bead spreader | synchronous clutch spreading, equipped with a speed-adjustable gear shifting device, single/double spreading can be selected according to needs 50-200mm | synchronous clutch spreading, equipped with a speed-adjustable gear shifting device, single/double spreading can be selected according to needs 50-200mm |
| Rear Wheel Directional Device | Ensure the machine moving in a straight line or turning freely on the curved road | Ensure the machine moving in a straight line or turning freely on a curved road |
| Brake | Using a drum brake, you can adjust the brake tension | Using a drum brake, you can adjust the brake tension |
| Marking width | Standard 150mm marking bucket 100mm、150mm、200mm、250mm、300mm、400mm、450mm (at customers’ option) | Standard 150mm marking bucket 100mm、150mm、200mm、250mm、300mm、400mm、450mm (at customers’ option) |
| Battery Capacity | 15AH | 15AH |
| Battery Voltage | 48V lithium battery | 48V lithium battery |
| Driver Speed | 1-8km/hour | 1-8km/hour |
| Working Duration | The machine can mark road lines24 hours after charging the battery5 hours | The machine can mark road lines24 hours after charging the battery5 hours |
| Dimensions | 1210X970X1070mm | 1200X970X1100mm |
| Net weight | 130kg | 150kg |
Hot Melt Paint Applicator features
- Capacity: We design our machines to accommodate large volumes of paint, making them ideal for both small and large-scale projects.
- Heating System: Equipped with an advanced heating system that ensures consistent temperature control for smooth and even paint application.
- Application Method: Can use both spray and extrusion methods, offering flexibility depending on the type of road surface and marking requirements.
- Engine Power: Robust engine power that ensures the machine operates smoothly even in challenging road conditions.
- Material Compatibility: Designed to work seamlessly with thermoplastic marking machines and other high-performance road marking materials.
- Temperature Control: Precise temperature control to ensure the paint maintains its optimal viscosity and consistency during the application process.
Advantages of Hot Melt Paint Applicator
- Durability and Longevity：Hot melt paint applicators create markings that are long-lasting and highly resistant to wear and tear. This makes them ideal for busy roads and highways where constant exposure to traffic, weather, and environmental factors could cause traditional markings to fade quickly.
- High Efficiency and Speed：We design these machines for fast application, saving time and labor costs. Whether you’re marking highways, parking lots, or city streets, Hot Melt Paint Applicator can complete the job in a fraction of the time compared to manual marking methods, making them a cost-effective choice for businesses.
- Consistency and Precision：With Road Marking Equipment like the hot melt paint applicator, the application of thermoplastic paint is precise and uniform. The machine’s automated system ensures consistent lines, reducing errors and the need for touch-ups, ultimately increasing the project’s overall quality.
- Eco-Friendly Solution：Unlike some traditional road marking methods, the use of hot melt paint applicators ensures that the markings are eco-friendly. The thermoplastic materials used in our machines are free from harmful chemicals and comply with global environmental standards.
- Reduced Maintenance Costs：The robust nature of the thermoplastic markings produced by hot melt road marking machines means that they require less frequent maintenance and reapplication. This helps reduce long-term maintenance costs and ensures better value for money.
- Weather Resistance：We design these machines to apply thermoplastic paints that resist wear from rain, snow, and extreme temperatures. This is crucial for areas that experience harsh weather conditions, ensuring that the road markings remain intact throughout the year.
Usage Scenarios for Hot Melt Road Marking Machine
- Highways and Main Roads：Thermoplastic road marking machine are perfect for marking high-traffic highways and main roads. These roads require markings that are durable and reflective, ensuring clear visibility for drivers, especially during the night or in rainy conditions.
- Parking Lots：Parking lots require clear and long-lasting markings to guide drivers. Road marking equipment like the hot melt road marking machine clearly defines and maintains parking spaces for an extended period, even under the weight of heavy vehicles.
- Urban Streets：In cities, road markings are essential for traffic management and pedestrian safety. The application of durable thermoplastic paint helps maintain the integrity of the markings, even in high-footfall areas where the road surface is constantly exposed to traffic and weather conditions.
- Airports：Airports use thermoplastic marking machines to ensure that runways, taxiways, and other critical areas are marked clearly for safety and operational efficiency.
- Construction Sites：Road markings on construction sites help manage traffic flow, guide vehicles, and ensure safety for both workers and drivers. The fast and durable application of road markings using hot melt road marking machines is essential in these high-stakes environments.
Customer Success Stories of Hot Melt Road Marking Machine
Case 1: A Highway Construction Project in USA
A major highway construction company in the United States used the thermoplastic road marking machine for a large project to mark lanes, pedestrian crossings, and traffic lines. The machine was able to complete the marking of 50 miles of road in just two weeks, providing durable, reflective lines that ensured driver safety. The company reported significant savings in labor costs and maintenance, thanks to the machine’s speed and durability.
Case 2: A City Road Safety Project in India
In a city road safety initiative, a municipal corporation in India invested in our thermoplastic marking machine to enhance road safety. With high levels of foot traffic and varying weather conditions, the hot melt road marking machine proved to be the ideal solution. The road markings have remained visible and intact, even during heavy rainfall and extreme temperatures, ensuring the safety of thousands of commuters every day.
YG Machinery: Your Trusted Partner in Road Marking Solutions
At YG Machinery, we specialize in high-quality hot melt road marking machines, offering reliable and cost-effective solutions backed by over 20 years of industry experience. Whether you need road marking equipment for highway construction or urban projects, we provide quality and cheap machines tailored to your needs. Our dedicated team supports you through every step of the purchasing process to ensure your satisfaction.
In addition to road marking machines, YG Machinery also offers a wide range of equipment, including floor shot blasters, road rollers, asphalt crack filler machines, floor grinder machines, concrete curb machines, electric road sweepers, electric snowblowers, trowel machines, hot melt kettles, and snow making machines—all with high quality and the best price. Contact us now to learn more.【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
