A mobile crusher machine is a powerful and portable crushing solution designed to process materials directly on-site. It eliminates the need for material transportation, thereby significantly reducing costs and improving efficiency. Moreover, portable crusher machines are widely used in construction, mining, and recycling industries, offering flexibility and convenience for various projects. Typically, mobile crushing machines adopt either a wheeled or tracked (crawler) mobility system, depending on the terrain and job site requirements：1.wheeled mobile crushers – Ideal for easily accessible job sites with solid ground conditions. They offer quick setup and efficient material processing. 2.tracked (crawler) mobile crushers – Designed for rough terrains and more challenging environments, providing superior stability and maneuverability.
Mobile Crusher Machine Parameter
| Model | 800×800 | 800×1000 | 1000×1200 | 1200×1200 | 1200×1500 | 1400×1600 |
| Motor Power | 90kw×4G | 110kw×4G | 132kw×4G | 160kw×4G | 185kw×4G | 250kw×4G |
| Diesel Power | 195HP | 195HP | 260HP | 330HP | 330HP | 400HP |
| Hopper | 3500×1800×8mm | 3600×2200×8mm | 3600×2200×8mm | 3800×2200×8mm | 3800×2200×8mm | 4000×2400×10mm |
| Hammerhead Weight | 15kg | 15kg | 20kg | 36kg | 36kg | 55kg |
| Total Weight | 10t | 12.5t | 14t | 19t | 21t | 26t |
| Belt | 7×0.8m | 8×0.8m | 8×1m | 8×1m | 8×1m | 9×1m |
| Belt Conveyor Power | 5.5kw | 5.5kw | 7.5kw | 7.5kw | 7.5kw | 7.5kw |
| Tyre Model×Number | 1100×8pcs | 1100×8pcs | 1100×8pcs | 1000×12pcs | 1100×12pcs | 1100×12pcs |
| Sand Capacity | 30t | 45t | 55t | 65t | 80t | 100t |
| Stone Capacity | 50t | 70t | 80t | 90t | 120t | 180t |
| Overall Size | 10*2.8*3.5m | 11*2.8*3.5m | 11.5*2.8*3.5m | 12*3*3.6m | 12*3*3.6m | 13*3.2*3.7m |
Types of Mobile Crusher Machine
- Mobile stone crusher machine
Best for on-site crushing of rocks and construction debris.
Produces high-quality aggregates for road and building construction.
Works efficiently in quarrying and demolition projects. - Portable crusher machine
Compact and easy to transport, perfect for remote locations.
Offers fast setup and dismantling, making it ideal for temporary projects.
Suitable for smaller-scale mining and urban demolition.
This category includes both small mobile crushers and mini mobile crushers:
small mobile crusher – Ideal for compact job sites with medium-scale crushing, mini mobile crusher – Perfect for minor crushing tasks in confined spaces. - Jaw crusher (mobile)
Designed for primary crushing, handling large-sized materials.
High crushing capacity and adjustable output size.
Perfect for mining operations and large-scale construction projects. - Hydraulic cone crusher (mobile)
Best for secondary and tertiary crushing.
Handles harder materials like granite, basalt, and iron ore.
Provides efficient multi-stage crushing solutions.
Advantages of a Small Mobile Crusher
- On-Site Crushing: Saves transportation costs and time.
- High Efficiency: Delivers strong crushing performance for various materials.
- Flexibility & Mobility: Easily transported between job sites.
- Cost-Effective: Reduces investment in multiple machines.
- Eco-Friendly: Minimizes dust and carbon footprint.
Applications of Mobile Crushers
- Construction Sites: Crushing concrete and asphalt for reuse.
- Mining & Quarrying: Processing rocks and minerals into aggregates.
- Road Construction: Producing materials for highways and infrastructure.
- Recycling Centers: Transforming waste into valuable materials.
How Does the Machine Work?
- Raw materials are fed into the jaw or cone crusher.
- The crusher breaks down materials into smaller sizes.
- Crushed materials are discharged and collected for use.
- Attachments like screens and conveyors help sort and transport materials efficiently.
YG Machinery:As one of the leading mobile crusher manufacturer, we offer
- High-quality mobile crushing plant for sale with long-lasting durability.
- Competitive mobile crushing plant prices to fit your budget.
- Reliable after-sales service and technical support.
- Customizable solutions to meet specific project needs.
Looking for the cheap mobile stone crusher machine price? Want expert advice on mobile crusher maintenance tips? Contact us today for premium crushing solutions tailored to your needs!【WhatsApp/WeChat/Skype/Phone】+86 13837115193
