A mud sucker pump is a vital piece of equipment used to move drilling fluids—such as mud or water—into a borehole during excavation and drilling operations. It is typically used alongside drilling rigs, air compressors, and drilling tools. Known for its durability and high-pressure performance, the pump plays a key role in flushing debris, stabilizing boreholes, and cooling drill bits. Widely used in mining, construction, and oilfield operations, its simple design, low maintenance, and reliable performance make it a cost-effective solution for slurry transport.Contact us for customized solutions: 【WhatsApp/WeChat/Phone/Skype】 +86 13837115193
Mud Sucker Pump Parameters
| Model | BW150 | BW160 | BW250 | BW320 |
| Max. traffic | 150L/min | 160L/min | 250L/min | 320L/min |
| Max. pressure | 7Mpa | 10Mpa | 6Mpa | 8Mpa |
| Power | 7.5kw | 11kw | 15kw | 30kw |
| Inlet pipe diameter | 51mm | 51mm | 76mm | 76mm |
| Outlet pipe diameter | 32mm | 32mm | 51mm | 51mm |
| Weight | 560kg | 480kg | 760kg | 1000kg |
YG Machinery offers a series of drilling mud pumps designed to meet different flow and pressure requirements. The models vary in flow rates from 150L/min to 320L/min and handle pressures from 6Mpa to 10Mpa. Their motor power ranges between 7.5kw and 30kw, making them suitable for light to heavy-duty applications. The weight and size of the pumps are optimized to support both fixed and mobile drilling systems.
Each model is built to ensure stable delivery of slurry without pulsation or shearing. Whether you’re using a small mud pump for minor drilling projects or need a higher-capacity version for deeper boreholes, YG’s product range has a suitable option.
Advantages of Drilling Mud Pump
One of the key advantages is the machine’s ability to handle high-viscosity and solid-laden fluids without clogging. Its piston-driven mechanism ensures smooth operation and minimal vibration, even under tough conditions. Since flow and pressure are not directly tied to rotation speed, it performs efficiently across varying demands.
Additionally, the pump offers strong self-priming ability, meaning it can start without external assistance. The direction of flow can also be reversed, which is useful for pipeline cleaning or flushing systems. These features make it especially appealing for operations in unpredictable environments.
Applications of Mud Pumps
They are widely applied in industries such as mining, metallurgy, coal processing, and environmental protection. In thermal power plants, they support hydraulic ash removal. In coal washing, they transport slurry and heavy media efficiently. Their corrosion resistance also makes them suitable for use in chemical plants where abrasive or crystalline slurries are handled.Contractors working on river dredging or foundation drilling also depend on this machine for efficient slurry movement. For mobile drilling teams, pairing this pump with small mud pumps ensures flexibility and ease of use in remote sites.
Why Choose YG as Your Mud Pump Supplier？
As one of the trusted mud pump suppliers in China, YG Machinery offers a wide selection of products backed by years of manufacturing expertise. Each unit is tested for quality and compatibility with a wide range of drilling systems.We also offer a variety of related equipment that pairs well with these pumps, including:Small water well drilling rigs,Crawler DTH drilling rigs,Horizontal directional drilling rigs,Core drilling rigs,Air compressors.Contact YG Machinery Today.【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
