A rebar cutting bending machine is an essential piece of equipment for modern construction sites. Designed to handle both cutting and bending of steel bars, this machine simplifies the process of rebar shaping, improves efficiency, and ensures precision. Its main advantages include high productivity, easy operation, and strong adaptability to different sizes of steel bars. Once the operator places the steel bars on the platform and aligns them with the guide, the machine automatically or semi-automatically processes them, ensuring precise results.
The Rebar Cutting Bending Machine Parameters
| Model | Technical Parameter | |
| YG-40/YG-40S | Motor Power(kW) | 2.2 |
| Rebar Diameter(mm) | 6-25 | |
| Round Bar Diameter(mm) | 6-26 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 300 | |
| Dimension(mm) | 1200*310*630 | |
| YG-40A | Motor Power(kW) | 3 |
| Rebar Diameter(mm) | 6-28 | |
| Round Bar Diameter(mm) | 6-35 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 330 | |
| Dimension(mm) | 1310*460*760 | |
| YG-40B | Motor Power(kW) | 3 |
| Rebar Diameter(mm) | 6-32 | |
| Round Bar Diameter(mm) | 6-35 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 350 | |
| Dimension(mm) | 1310*460*760 | |
| YG-42 | Motor Power(kW) | 3 |
| Rebar Diameter(mm) | 6-32 | |
| Round Bar Diameter(mm) | 6-40 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 380 | |
| Dimension(mm) | 1330*460*790 | |
| YG-45 | Motor Power(kW) | 4 |
| Rebar Diameter(mm) | 6-32 | |
| Round Bar Diameter(mm) | 6-40 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 400 | |
| Dimension(mm) | 1330*460*790 | |
| YG-50 | Motor Power(kW) | 4 |
| Rebar Diameter(mm) | 6-40 | |
| Round Bar Diameter(mm) | 6-45 | |
| Cutting Number(times/min) | 28 | |
| Weight(kg) | 480 | |
| Dimension(mm) | 1410*460*810 | |
| YG-40 Straight Thread Rebar | Motor Power(kW) | 3 |
| Rebar Diameter(mm) | 6-28 | |
| Round Bar Diameter(mm) | 6-35 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 370 | |
| Dimension(mm) | 1330*460*790 | |
| YG-45 Straight Thread Rebar | Motor Power(kW) | 4 |
| Rebar Diameter(mm) | 6-32 | |
| Round Bar Diameter(mm) | 6-40 | |
| Cutting Number(times/min) | 32 | |
| Weight(kg) | 410 | |
| Dimension(mm) | 1330*460*790 | |
| YG-50 Straight Thread Rebar | Motor Power(kW) | 4 |
| Rebar Diameter(mm) | 6-40 | |
| Round Bar Diameter(mm) | 6-50 | |
| Cutting Number(times/min) | 28 | |
| Weight(kg) | 510 | |
| Dimension(mm) | 1410*460*810 | |
| YG-50 Angled Steel Bar | Motor Power(kW) | 4 |
| Angled Bar Diameter(mm) | ≤100*100*10 | |
| Cutting Number(times/min) | 28 | |
| Weight(kg) | 580 | |
| Dimension(mm) | 1440*460*810 | |
| YG-50 Flat Steel Bar | Motor Power(kW) | 4 |
| Flat Bar Diameter(mm) | 150*10 | |
| Cutting Number(times/min) | 28 | |
| Weight(kg) | 580 | |
| Dimension(mm) | 1440*460*810 | |
Main Functions of the Rebar Cutting Bending Machine
This versatile machine integrates cutting and bending into one system. It can process various types of rebar including carbon steel, hot rolled steel, and deformed bars. With models like YG-40, YG-45, and YG-50 available, each one is equipped with different power levels (ranging from 2.2kW to 4kW) and processing capacities, allowing customers to select the most suitable option based on their specific needs.
Most machines offer a cutting speed of up to 32 times per minute and handle steel bars with diameters ranging from 6mm to 50mm. Their compact dimensions and weight make them easy to transport and set up on different job sites.
How Steel Bending and Cutting Machine Works?
The working principle of a rebar cutting bending machine is simple yet effective. A powerful motor drives both the cutting and bending components, while the gear systems ensure smooth and efficient operation. Once the operator places the steel bars on the platform and aligns them with the guide, the machine processes them using either automated or semi-automated controls, ensuring precise results. The machine uses high-strength blades for cutting and a precisely calibrated angle setter for bending, guaranteeing accurate shapes with minimal labor.
Advantages of Rebar Cutting and Bending Machine
One of the key strengths of this equipment is its dual functionality. Instead of purchasing two separate machines, users can benefit from both cutting and bending functions in a single, compact unit. This not only saves valuable space but also results in significant cost savings. Furthermore, the cutting and bending operations are both fast and precise, ensuring high efficiency and accuracy in every task. The high-quality bearings and gears in the machine contribute to its long service life and minimal mechanical loss. In addition, most models come equipped with wheels, making it easy to relocate the machine across construction sites. Another notable advantage is the enhanced safety features; the design incorporates protective covers and clear operational guidelines, which significantly reduce the risk of injury during use.
Applications of Rebar Cutting Bending Machine
The mechine is suitable for various types of construction projects.
1. Bridge and tunnel projects require large volumes of rebar.
2. High-rise buildings need complex bending angles for structural reinforcement.
3. Road and highway projects that demand consistent steel bar shapes for support structures.
4. Prefabricated building sites where quick and accurate processing of rebar is essential.
Whether you’re a construction company, contractor, or equipment rental provider, this machine offers a practical, cost-effective solution for rebar processing, making it an invaluable addition to any project.
Steel Bar Cutting Machine Price
When researching the bar cutting machine price, it’s important to look beyond just the upfront cost. Consider factors like cutting capacity, motor power, build quality, and ease of maintenance. YG Machinery provides competitive pricing along with customization options, helping customers get the best value for their investment. Whether you’re looking for a compact portable unit or a robust heavy-duty workshop model, there’s a machine available that perfectly aligns with both your budget and performance needs.
Bar Cutting Machine Price in YG Machinery
YG Machinery is a trusted manufacturer with years of experience producing construction and engineering equipment. We are committed to delivering high-quality machines that meet the needs of various industries. All machines are produced under strict quality control standards and are backed by professional support and service.Apart from rebar processing machines, we also offer a wide range of other machinery, including: hydraulic wire saw, stone wire saw, mini excavators, electric wire saw, tracked aerial lifts, portable container houses, screw pile drivers. If you’re looking for a high-performance rebar cutting bending machine, please contact YG Machinery:【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
