In today’s fast growing FMCG industry, an efficient tea cup making machine has become the core competitiveness of a beverage company. YG has launched a low price paper cup machine, which raises the production speed of cups to 80-100 per minute, providing low-cost entrepreneurs with YG launched low price paper cup machine to increase the production speed to 80-100 cups per minute, providing a good choice for low cost entrepreneurs.
Tea Cup Making Machine Parameter
| Model | YG-M100 |
| Paper Cup Size | 3-16 OZ |
| Raw Material | One-side or two-side PE coated paper(Singe PE or Double PE coated paper) |
| Speed | 80-100pcs/min |
| Suitable paper weight | 160-260g/㎡；±20g/㎡ |
| Voltage supply | 380V(220V) 50HZ |
| cup size | bottom28-54mm，top40-75mm，high30-95mm |
| Working Air Source | 0.4-0.6Mpa; 0.4m³/min |
| General power | 4.5kw |
| Net weight | 1500kg |
| Cup Side Sealing | Ultrasonic |
| Bottom Knurling | HOT AIR SYSTEM |
| We can customize the machine and mold according to the customer’s requirements!!! | |
Tea Cup Manufacturing Machine Advantages
- Heat sealing precision control system
Real-time monitoring of the welding temperature (185±2℃) at the bottom of the cup through infrared rays, together with the servo motor-driven paper feeding mechanism, it reduces the leakage rate, which is commonly found in the traditional equipment, from 3% to less than 0.5%. - Intelligent Energy Saving Module
Innovative thermal storage heating system can recover 80% of the waste heat, which saves about 45,000 kWh of electricity consumption per year compared to ordinary cup manufacturing machine. - Quick mold changeover device
With the magnetic mold design, the cup changeover time is shortened from the traditional 25 minutes to 90 seconds, which is especially suitable for the production of tea cups with different capacities from 100-500ml.
Operational Safety and Maintenance Points
During a visit to the workshop of a large chain of tea drink suppliers, we noticed the impact of standardized operation on the life of the equipment:
- Hydraulic oil level needs to be checked before startup every day (it is recommended to keep it at 2/3 of the sight window);
- Ultrasonic sealing assembly needs to be cleaned of adhesive residue every 8 hours (using a special ceramic scraper);
- Emergency braking buttons must be kept free of obstacles within an effective working radius of 1.5 m. The machine must be operated in a safe manner, so that it can be operated in a safe manner and be able to handle all types of cups and glasses;
In response to the common problem of paper cup crimping and folding, the YG engineer team has developed a dynamic tension compensation algorithm, which adjusts the feeding pressure in real time through 16 sets of sensors, so that the yield rate is stabilized at more than 99.2%.
Market Differentiation Advantages
Compared with the paper cup making machine low price models on the market, YG equipment establishes barriers in three dimensions:
- Adopting food-grade 304 stainless steel conveyor rail, which is certified by SGS;
- Equipped with IOT remote diagnostic interface as standard, which shortens the fault response time by 60%;
- Supporting processing of environmentally friendly materials, such as PLA lamination paper, to adapt to the requirements of the global plastic ban. Adapt to the requirements of the global plastic ban;
After the introduction of our production line to an international coffee brand, the production capacity of a single shift was increased to 80,000 pieces, while saving about 270,000 RMB per year in raw material costs due to the precise wax coating control technology.
Paper Cup Making Machine Low Price in YG
As a leading packaging equipment manufacturer in Asia, YG is committed to providing customers with high quality and low price products. For example, the following synergistic equipment: high speed paper cup machine, paper cup making machine, paper plate making machine and other products. Contact us to know more details now! 【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
