Trailer Mounted Water Well Drilling Rigs for Sale

trailer mounted water well drilling rigs for sale
trailer mounted water well drilling rigs for sale
water well rig price
water well rig price

When looking for portable drilling equipment suitable for different scenarios such as rural areas, farms, construction sites, etc., the trailer mounted water well drilling rigs for sale from YG have become the center of attention in the market. These rigs are well-designed, easy to operate, and convenient to move, making them ideal for a wide range of applications such as water well drilling, irrigation well construction, and geological surveys. Customers usually focus on key factors such as drilling for water cost, drilling depth, service life and parts availability.

Request A Quote

YG Trailer Mounted Water Well Drilling Rigs Parameters

Tech ParameterXY-3XYD-3XYX-3
Drilling Depth (m)600600600
Open Hole Diameter (mm)325325325
End Hole Diameter (mm)757575
Drill Angle (°)90~7590~7590~75
Matching Power (kW)YN27/42YN33GBZ/65YN27/42
Weight Without Power (kg)180062003600
Dimension (m)2.6×0.9×1.754.5×2×2.72.9×2.56×3.3
Spindle Speed (r/min)32~105732~105732~1057
Spindle Stroke (mm)600600600
Max Pull Force (kg)300045003000
Pull Speed (m/s)0.3~1.90.3~1.90.3~1.9
Rope Diameter (mm)Ø12.5Ø12.5Ø12.5
Roll Capacity (m)656565
Rated Load (ton)181818
Effective Height (m)116.56.5

Request A Quote

Major Factors Affecting Drilling for Water Cost

In terms of drilling for water cost, which is a common concern for customers, the cost components usually include equipment purchase cost, construction depth, formation complexity, drilling tools wear and tear, as well as the length of the construction period, etc. YG’s trailer mounted drilling rigs have been widely recognized as the best choice for drilling for water.
YG’s trailer mounted water well drilling rigs for sale are significantly lower than similar products in the market due to their cost-effective, low-maintenance design and easy-to-replace drilling tools.
At the same time, the portability of the equipment reduces transportation and transit costs, further reducing the total investment.

Request A Quote

FAQ

  1. How deep can this water well rig drill?

The standard configuration can drill up to 200 meters, depending on the geological conditions.

2.What are the advantages of portable well drilling machine?

The trailer design is easy to transfer and suitable for long-distance road transportation; it is more powerful and has a larger drilling diameter and depth.

  1. Is it complicated to operate?

The machine is easy to operate and a novice can be trained in 1-2 days. YG provides a full operating video and manual.

  1. How much does drilling for water cost?

Depending on the depth of the hole, the local geology and the time of construction.

5.Is there a complete set of drilling tools?

YG provides standard drilling rods, drill bits, mud pumps and other accessories, which can be customized according to your needs.

Request A Quote

Trailer Mounted Water Well Drilling Rigs for Sale in YG

YG, as a professional manufacturer of drilling equipment, offers a wide range of water well rigs, including portable well drilling machine and truck mounted drilling rigs, hydraulic core drilling rigs and so on. Our products comply with the latest technical standards in 2023, guaranteeing safety, durability, easy operation and perfect after-sales service, and have been exported to Southeast Asia, Africa, South America and other regions.
