Anchor drilling machine (Anchor drilling machine) is a kind of high efficient drilling equipment used for foundation reinforcement, slope stabilization and tunnel support, which is specially designed for drilling anchor holes (i.e. drilling rig anchors) in order to install ground anchoring systems to achieve structural stability, prevent landslides, collapses or support works destabilization.
This equipment is widely used in highway, high-speed railway, hydroelectric power station, pit protection, slope management, mine support and other projects, especially suitable for difficult drilling tasks under complex geological conditions.
Multi-angle drilling function: supports vertical, horizontal and inclined drilling, which is suitable for various construction scenarios.
Adaptable to a variety of drilling tools: can be used with submerged hammers, alloy bits, auger bits, etc. to adapt to different stratigraphic conditions.
Crawler chassis design: easy to walk flexibly and work stably in complex mountains and muddy areas.
High-power hydraulic system: provides strong power, ensures efficient penetration ability and shortens construction period.
Intelligent operating system: with integrated control panel and automatic deflection correction system, reducing operation difficulty and improving accuracy.
Compact structure and easy transportation: compact design, convenient for lifting, loading and transferring operations.
The Difference Between the 2 Types of Anchoring Drilling Rigs
Types
Ground Anchor Drilling Rig
Rock Anchor Drilling Machine
Applicable Geology
Soil, sand, weathered rock
Hard rock, strongly weathered layers
Main Application
Slope stabilization, foundation anchoring, construction base
Tunnel support, mining anchor drilling
Drilling Method
Rotary drilling, auger drilling
Percussive drilling, DTH drilling
Power System
Medium-low power hydraulic system
High-pressure hydraulic or pneumatic system
Drilling Efficiency
Moderate
High
If you are facing soft soil or general slope management project, you can choose ground anchor drilling rig; while in rock or underground tunnel support construction, rock anchor drilling machine is more recommended.
Q1: What is the anchor drilling rig price? A: The price of anchor drilling rig is affected by the model, configuration, drilling depth, supporting power system, etc. YG Machinery provides a variety of models to support customization, you can contact us for a specific quote. [WhatsApp/WeChat/Phone] +86 13837115193.
Q2: How many meters can an anchor drilling rig drill in a day? A: Depending on the geological conditions and the type of drill bit, it can generally accomplish drilling tasks ranging from 50-120 meters a day.
Q3：Does anchor drilling rig support high angle or elevation drilling? A: Yes, most anchor drilling machines are equipped with hydraulic angle adjustment mechanism, which can flexibly realize vertical, elevation or horizontal drilling.
Q4: Is it possible to change different types of drill bits? A: Yes. According to the type of stratum, we can change suitable drill bit, including auger bit, down hole hammer bit, alloy bit and so on.
Geological conditions must be detected before construction to select suitable drilling method and drill bit.
Ensure that the legs are smoothly supported before the operation of the drilling rig, so as to prevent it from tipping or shifting during the operation.
Check the hydraulic system and lubrication system regularly to keep the machine running stably.
Operators should receive professional training and be familiar with all kinds of buttons and emergency operation procedures.
Pay attention to prevent high temperature overload and equipment jamming during the operation to avoid damaging the drill bit and hydraulic motor.
Night construction should be equipped with sufficient lighting, and the construction area should be well fenced off for safety warnings.
