In the field of building decoration, GRC spray machine is revolutionizing traditional construction methods with high-precision spraying and industrial-grade efficiency. Designed for GRC (glass fiber reinforced cement), this spraying machine increases the construction efficiency of complex components by 300% through the intelligent material conveying and fiber cutting system, while ensuring that the strength of the finished product reaches the C30-C50 concrete standard.
CorGRC Spray Machine Parameter
| Product name | Glass Fiber Reinforced Concrete GRC Spray Machine |
| Power | 2.2-4.0kw |
| Voltage | 380v 50hz |
| Speed | 20-200r/min |
| Workspace | 4.5m |
| Delivery capacity | 300-1600kg/h |
| Production efficiency | 200-400m2/h |
| Volume | 60L |
| Dimension for the sprayer | 2000*1050*1600mm |
| Dimension for the mixer | 1550*1000*2100mm |
| Total weight | 800kgs |
Traditional Sprayers vs GRC Equipment
- Coaxial Gun Technology: solves the industry pain point of uneven mixing of mortar and fiber.
- Modular Disassembly: maintenance time is reduced to 30 minutes (2 hours for competitors).
- Optimization of Energy Consumption: 18% reduction in energy consumption per square meter.
Three high-value application scenarios
- Landmark Building Curtain Wall: GRC European-style components project for a hotel in Dubai, 20,000 square meters of curved relief spraying completed in 7 days (GRC machines efficiency benchmark case).
- Transportation Noise Reduction Project: Malaysia high-speed rail sound insulation panel production line, the yield rate increased to 99.2%.
- Ecological Landscape Production: Sanya resort artificial rock wall project, comprehensive cost savings of 400,000 yuan.
Gold Standard for Customer Purchase
Decision-making should focus on the following core dimensions:
- Construction Compatibility: whether it can be adapted to different reinforcing materials such as glass fiber/basalt fiber, etc.
- Mobility: universal wheels + compact body (2m×1m) for narrow construction sites.
- Life Cycle Cost: YG equipment rotor life of 8,000 hours, 35% higher than peers.
- Safe and Redundant Design: dual pressure sensors + automatic pressure relief device.
Brief analysis of the working principle
After the material is pressurized by the screw pump, the instant mixing of mortar and cutting fiber is realized by the same core spray gun, and the fan spray is formed by the precision air control system. The key link adopts German FESTO pneumatic components to ensure that the fluctuation of spray pressure per square centimeter is ≤0.1MPa.
Attachment: operation safety instructions
- Strictly prohibit over 380V voltage operation.
- Flush the pipeline with water for 30 minutes after each operation.
- Fiber cutting area must be equipped with protective cover.
Made by YG: GRC solutions trusted worldwide
As a GRC equipment manufacturer with 16 years of experience, YG Machinery has supplied spraying systems to 42 countries around the world. We also have the following products: polyurethane machine, polyurea spray machine, cement mortar spraying machine, etc. Contact us to know more details now!【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
