A hydraulic rotary drilling rig is a vital construction machine used to create deep holes for foundations in various construction projects. Its efficient design and hydraulic technology make it ideal for use in challenging geological conditions, offering a reliable solution for foundation construction in industries such as urban building projects, bridges, and high-speed rail construction. The main advantages of these rigs include fast drilling speeds, reduced labor intensity, and low environmental impact.
Hydraulic Rotary Drilling Rig Parameters
YG’s drilling rig comes with a range of powerful specifications designed to meet the demands of diverse projects:
| Dimensions (mm) | 7900*2260*3100 |
| Vehicle mass (kg) | 8000 |
| Wheelbase (mm) | 3150 |
| Wheelbase (mm) | Front 1400 After 1060 |
| Drilling depth (m) | 13 |
| Drilling diameter (mm) | 600-1600 |
| Rotation angle | 180 degree |
| Walking speed (km/h) | 50 |
| Gear pump model | CBJT2080 |
| Hydraulic system working pressure (Mpa) | 20-25 |
| Hydraulic system displacement (ml/r) | 80 |
| engine model | 4108 |
| Engine power (kW) | 88 |
What is a Hydraulic Rotary Drilling Rig?
The machine uses hydraulic power to drive a rotating drill bit, allowing it to penetrate different soil types and rock layers with ease. This equipment is perfect for large-scale construction projects that require deep foundations. The system’s high efficiency, coupled with its ability to operate in varied geological environments, makes it the go-to choice for pile foundation work, hole formation, and wall protection.
Key Features and Advantages
- High Efficiency: The hydraulic system provides strong rotational power and precise control, ensuring fast hole drilling even in tough soils or rock formations.
- Cost-Effective: By reducing labor intensity and operational costs, these rigs offer long-term value. Their advanced design minimizes auxiliary time during drilling.
- Environmental Friendliness: Unlike some traditional rigs, the machine minimizes environmental disruption, making it a great choice for urban construction and environmentally-sensitive projects.
Application Areas of Hydraulic Rotary Drilling Rig
The drilling rig is primarily used in projects requiring deep foundation work. Its primary applications include:
- Urban Construction: For high-rise buildings and residential projects, the rig ensures strong and stable foundation piles.
- Bridge Construction: Ideal for the formation of deep piles and foundation reinforcement.
- Slope Protection & Retaining Walls: The rig plays a crucial role in creating foundations for slope protection systems and retaining walls in civil engineering projects.
- Power Grid Projects: Used for drilling in power grid foundation construction, ensuring the stability of poles and supports.
How Hydraulic Rotary Drilling Rig Works?
The rig works by utilizing a high-powered hydraulic system to rotate a drill bit. As the drill bit rotates, it cuts through soil, rock, or other materials to form a precise hole for foundation piles. The hydraulic system’s pressure and flow rate are adjustable, allowing operators to customize drilling parameters based on the geological conditions and project requirements. The rotary drilling machine price is often influenced by these technical capabilities and the machine’s versatility.
Choosing the Right Hydraulic Rotary Drilling Rig
When selecting a drilling rig, it’s essential to consider several factors:
- Project Type and Scale: Ensure that the rig can handle the specific demands of your project, such as drilling depth and diameter.
- Geological Conditions: Different rigs are suited to different geological conditions, such as soft soils, hard rock layers, or pebbled ground.
- Price and Budget: Evaluate the rotary drilling machine price to ensure it fits your budget without compromising on quality. YG Machinery offers competitive pricing for high-quality rigs.
YG Machinery: Your Trusted Partner Manufacturer
YG Machinery is a leading manufacturer of high-quality hydraulic rotary drilling rigs, offering advanced features, exceptional performance, and competitive prices. In addition, YG offers a wide range of equipment, including excavators, hydraulic pile drivers, and core drilling machines, etc.
Contact YG today for more information.【WhatsApp/WeChat/Phone/Skype】+86 13837115193.
