YG Sludge Cleaning Robot: Safe, Efficient, Unmanned Dredging Solution

In modern environmental governance, industrial oil tank maintenance, and water treatment, traditional manual methods for cleaning oil tanks, sedimentation tanks, or sludge ponds are costly, risky, and inefficient. YG’s sludge cleaning robot offers an intelligent, unmanned solution, making industrial dredging operations safer, more efficient, and more reliable.

Whether it’s municipal sewage ponds, chemical sedimentation tanks, aquaculture ponds, or oil storage tanks, the portable robotic dredge can handle the cleaning of sludge and sediment in complex environments.

Request A Quote

Sludge Cleaning Robot Parameters

Parameter	YG500	YG600	YG700	YG800	YG900	YG1200
Robot Dimensions (mm)	1500*500*650	1500*600*650	1600*700*650	1600*850*700	1650*960*750	1900*1200*750
Dredging Width (mm)	500	600	700	800	900	Suitable for large culverts
Travel Speed (m/s)	3–15	3–15	3–15	3–15	3–15	0–17 m/min
Pump Diameter (inch)	3	3	4	4	4	4or6
Pump Flow (m³/h)	100	100	160	160	200	250
Pump Head (m)	0–30	0–30	0–25	0–25	0–25	0–30 (Horizontal: 100–150m)
Hydraulic Station Dimensions (mm)	2200*1200*1700	2200*1200*1700	2200*1200*1700	2200*1200*1700	2200*1200*1700	2120*1240*1200
Main Motor Power (kW)	18	18	22	22	22	45KW (50KW) or Diesel 76KW (123KW)
Hydraulic System Pressure (Mpa)	0–16	0–16	0–16	0–16	0–16	Not specified
Particle Size (mm)	15	15	40	40	50	0–40 (customizable)
Winch Speed (r/min)	0–10	0–10	0–10	0–10	0–10	0–10
Pipe Length (m)	30–50 Optional	30–50 Optional	30–50 Optional	30–50 Optional	30–50 Optional	30m/pack, 20kg pressure resistant, optional
Control System	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote	Wireless Remote
Lighting System	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2	Underwater LED*2

Request A Quote

Unique Features of the Sludge Cleaning Robot

① Unmanned Dredging Solution

• Controlled wirelessly or via wired remote, the entire sludge cleaning process requires no personnel entering the water.
• Remote operation reduces the risk of high-risk operations.
• Supports real-time monitoring for more precise operation.

② High-Efficiency Sludge Pump System

• Large flow rate and high head, adaptable to sludge of varying concentrations and particle sizes.
• Anti-clogging design allows for continuous operation for 8–12 hours.
• Suitable for high-viscosity environments such as oil tanks, chemical pools, and sedimentation tanks.

③ Portable Tracked Chassis (Crawler/Portable Robotic Dredge)

• Tracked design adapts to soft mud, silt, and sediment.
• Corrosion-resistant, rust-resistant, and slip-resistant, providing high stability.
• Easy to transport to different work sites.

④ Explosion-Proof and Safety Design

• Explosion-proof motor and fully enclosed electrical control system.
• Suitable for hazardous environments such as petroleum and chemical plants.
• Improves equipment lifespan and operational safety.

Request A Quote

Common Application Scenarios of Robotic Dredge

YG sludge cleaning robot Widely applicable to:

• Municipal lakes and landscape lakes: Removing silt and algae deposits to restore water quality.
• Aquaculture ponds and farm ponds: Cleaning accumulated organic matter and improving the aquaculture environment.
• Chemical plant sedimentation tanks and wastewater treatment plants: Removing high-concentration sludge and industrial sediments.
• Oil tank cleaning: Removing sediment from the bottom of oil tanks, reducing the risks associated with manual operation.

Request A Quote

Nigerian Oil Tank Cleaning Case Study

In 2025, a Nigerian oil company purchased YG sludge cleaning robots for cleaning sediment from the bottom of multiple oil tanks.

Customer Pain Points:

• Manual entry into oil tanks poses risks of poisoning, suffocation, and fire.
• Traditional methods are costly and inefficient.
• The confined space in oil tanks makes operation impossible with ship-type or large machinery.

Solution:

• Using a portable robotic dredge for fully automated operation.
• Explosion-proof motors + visual monitoring ensure safety.
• High-flow sludge pumps quickly clean up deposited sludge.

Actual Results:

• Cleaning time for each oil tank reduced by 60%.
• Manual risks completely eliminated.
• The customer subsequently added multiple units for other storage tanks.

Customer Feedback: “This robotic dredge completely solved our long-standing oil tank cleaning problem; it’s safe, efficient, and economical.”

Request A Quote

FAQs about Portable Robotic Dredge

Q1: Can this sludge cleaning robot handle sludge of varying viscosities?

A1: Yes, the equipment’s sludge pump can handle different concentrations and particle sizes, including high-viscosity sludge and industrial sediments.

Q2: Is the equipment suitable for small oil tanks or confined ponds?

A2: Absolutely. The tracked chassis and compact design allow the portable robotic dredge to operate in confined spaces.

Q3: Is it complex to operate? Does it require specialized skills?

A3: No. It is fully unmanned, with remote visual monitoring, and can be used immediately with the accompanying training.

Q4: Is it suitable for chemical plants or flammable environments?

A4: Yes, the equipment uses explosion-proof motors and a fully enclosed electrical control system, making it safe for use in oil or chemical environments.

Q5: Are maintenance costs high?

A5: The equipment is durable and easy to maintain. Regular checks of the mud pump and tracked system are sufficient; overall operating costs are lower than manual operation.

Request A Quote

Why Choose YG Machinery?

• Professional Manufacturing Experience: 18+ years of experience in machinery manufacturing, specializing in environmental protection and industrial robots.
• Global Customer Trust: Serving over 30 countries.
• Multi-Scenario Applications: Covers lakes, ponds, oil tanks, and chemical sedimentation tanks.
• Customizable Design: Mud pumps, cameras, and track width can be adjusted to meet specific needs.
• Comprehensive After-Sales Service: Remote commissioning, video guidance, and spare parts supply.

Sludge Cleaning Robot in YG Machinery

If you are looking for a safe, efficient, and unmanned dredging device, the YG sludge cleaning robot is the ideal choice. Whether it’s lakes, aquaculture ponds, chemical plant sedimentation tanks, or sediment at the bottom of oil tanks, it provides a reliable unmanned dredging solution, making dredging work easier, safer, and more cost-effective.
