In modern cities and large-scale engineering projects, road cleaning is not only about environmental aesthetics but also impacts traffic safety. Compared to traditional road sweepers, the Truck-Mounted Road Sweeping Machine (vehicle-mounted road sweeper) has become the preferred choice for municipal sanitation departments and construction companies due to its higher cleaning efficiency and greater adaptability.
Truck-Mounted Road Sweeping Machine Parameters
| road sweeper truck Specification | Value |
| Vehicle Model | YG Road Sweeper Truck |
| Chassis Model | EQ1125SJ8CDC |
| Gross Weight | 11995 kg |
| Curb Weight | 7400 kg |
| Rated Load Capacity | 4400 kg |
| Wheelbase | 3800 mm |
| Clean Water Tank Volume | 4 m³ |
| Garbage Box Volume | 5 m³ (Stainless steel) |
| Tire Model | 245/70R19.5 / 8.25R20 |
| Sweeping Width | 2800-3200 mm |
| Emission Standard | GB3847-2005, GB17691-2018 China VI |
| Vehicle Dimensions (L×W×H) | 7000×2200×2700 mm |
| Main Engine Model (Chassis Engine) | Yunnei D25TCIF1, Yuchai YCY30165-60 (optional) |
| Horsepower (Main Engine) | Yunnei 150 HP, Yuchai 165 HP |
| Displacement (Main Engine) | Yunnei 2499 ml, Yuchai 2970 ml |
| Auxiliary Engine Model & Manufacturer | B140 33 (Dongfeng Cummins Co., Ltd.) |
| Auxiliary Engine Power | 102 kW |
| Auxiliary Engine Horsepower | 140 HP |
| Auxiliary Engine Displacement | 3200 ml |
| Sweeping Speed | 3-15 km/h |
| Maintenance Speed | 15-20 km/h |
| Max Sweeping Capacity | 38000 m²/h |
| Density | 2.0 g/cm³ |
| Garbage Box Dumping Angle | ≥30° |
| Sweeping Efficiency | ≥96% |
| Operating Noise | <88 dB (Compliant with GB7258) |
| Sweeping System Type | Two symmetrical lifting and extending side brushes driven by hydraulic motors |
| Main Components | Brush holder, brush, oil cylinder, hoses, linkages, hydraulic motor |
| Brush Expansion Diameter | φ800-900 mm |
| Brush Motor Speed | 140 r/min |
| Number of Brushes | 2 |
| Brush Tilt Adjustment | Forward tilt 5°-15°, outward tilt 5°-10° |
| Nozzle Device Type | Double suction nozzle with adjustable height and built-in high-pressure spray bar (8 nozzles) |
| Suction Pipe Diameter | φ180 mm |
| Suction Pipe Brand | NORRES |
| Walking Wheel Bearing | SKF |
| Wear-resistant Outer Ring | Stellana |
| Ground Clearance of Nozzle | 5-8 mm |
| Suction Airflow Speed | 50-65 m/s |
| Nozzle Negative Pressure | 380 mmH2O |
| Alarm System | Reverse voice alarm system |
| Auxiliary Control System | Tail-mounted electric control system for lifting and door operation |
| Manual Pump Emergency Lift System | Manual pump system for emergency lifting of brushes and hopper |
Features and Advantages of the Truck-Mounted Road Sweeper
This Truck-Mounted Road Sweeping Machine is built on a Dongfeng EQ1125SJ8CDC chassis, equipped with powerful engines and advanced sweeping systems, offering the following notable advantages:
- Large-capacity design for extended operation
Fresh water tank capacity: 4 m³, ensuring continuous water spraying to reduce dust.
Waste bin capacity: 5 m³ stainless steel material, corrosion-resistant and rust-proof, easily handling large-scale sweeping tasks. - Efficient Sweeping System
Sweeping width: 2800–3200 mm
Maximum sweeping capacity: 38,000 m²/h, covering a larger area in a single operation.
Symmetrical hydraulic-driven side brushes on both sides, combined with dual suction nozzles and high-pressure spray, effectively remove dust and gravel. - Powerful and stable performance
Chassis engine: Yunnei 150 HP or Yuchai 165 HP, providing ample power.
Auxiliary engine: Cummins 102 kW, ensuring continuous and efficient operation of the vacuum system. - Compliant with environmental and safety standards
Emissions standard: China National VI (GB17691-2018).
Low-noise design (<88 dB), compliant with GB7258 standards, reducing noise pollution.
Application Scenarios of Truck-Mounted Road Sweeper
- Municipal road cleaning: Meets municipal sweeper requirements, keeping the city clean around the clock.
- Highways and large squares: High operating speed (3-15 km/h), efficiently completing long-distance cleaning.
- Industrial and mining enterprises and construction sites: Reduces dust pollution, ensuring a safe construction environment.
Maintenance and Care Tips
- Regularly inspect the freshwater pump and high-pressure nozzles to ensure the water spray system remains unobstructed.
- Check hydraulic system pressure and promptly replace worn side brushes.
- Clean the waste bin to ensure the drainage system is free of blockages.
- Conduct monthly comprehensive maintenance, including lubrication, filter replacement, and electrical control system inspection.
Customer Case: South American Municipal Sanitation Project
A major city in South America purchased 10 Truck-Mounted Road Sweeping Machines to address the rapidly growing demand for road cleaning. After deployment, cleaning efficiency increased by 40%, with a single cleaning cycle covering over 20 kilometers. The machine’s operational stability and environmental performance received high praise. The project manager stated: “YG’s equipment not only delivers robust performance but also offers the advantages of easy maintenance and a flexible chassis, truly addressing the pain points of municipal sanitation.”
Why Choose YG Machinery?
As professional road sweeper manufacturers, YG Machinery offers a variety of street sweeper models, including electric sweepers, compact sweepers, and loader-mounted sweepers. Products support customized solutions, catering to diverse applications such as municipal, highway, and industrial/mining environments. Additionally, we provide comprehensive after-sales service and spare parts supply to ensure long-term worry-free use for our customers.
